Applications
- Domestic use in Bungalows, Hotels, Farm Houses and Hospitals that uses Solar / Wind power generation systems
|
|
Parameter
|
Value
|
|
Rated Torque (Nm)
|
2.1 Nm
|
|
Input Power (W)
|
750 W
|
|
Rated Voltage (V)
|
36 V (Also available in 48, 60 VDC)
|
|
Rated Speed (RPM)
|
3000
|
|
Rated Current (A)
|
20 A
|
|
Peak Current (A)
|
25 A
|
|
Winding Type
|
3 Phase Star Connected
|
|
Insulation Class
|
Class B
|
|
Magnet Temperature ( º C)
|
80 º
|
|
Hall Effect Angle (electrical angle)
|
120 º
|
|
Shaft Rotation Direction
|
Anti-clockwise
|
|
Pipe Size Inlet - Outlet
|
1 inch - ¾ inch
|
|
Discharge in Liters per hour
|
2080 (15 Head)
|
|
